Main feature：

■ Inside high frequency transformer isolation

■ Full hot plug design

■ TUV CE/UL, KC Certicification, EMC class B level

■ Air duct isolation design for high protection and high reliability for harsh environment

■ Wide output voltage range, 150-1000VDC, suitable for a wide range of EVs

■ Constant current for higher output power at low output voltage

■ Super denoise mode can get less 55 dB fan audio noise

■ An internal patented intelligent discharge circuit automatically discharges residual charge, simplifying system designs

■ Low standby power consumption with 12W. Super standy power consumption with 2W.

■ 3 phase without neutral eliminates the risk of high neutral currents

■ 3 phase active power factor correction technology, reduces the harmonic interference to the grid

■ Dual DSP design, provides the full digital control ,less components means higher reliability

■ Wide input voltage range, 260~530Vac, allows operation in most poor grid conditions

■ Wide operating temperature range, -40℃--+75℃

Application：

■ DC Charger for EV with modular design, easily maintenance, cost efficiency, high power density and high quality
